FJT-9309 is a high-performance passenger elevator designed for modern high-rise commercial, residential, and hospitality projects. Combining advanced permanent magnet synchronous gearless traction technology with elegant cabin aesthetics, this model ensures smooth, silent, energy-efficient vertical transportation with international safety standards.
It is the most popular model for premium office buildings, 5-star hotels, and luxury apartments in Bangladesh and Southeast Asia.
Key Features & Advantages:
1. Advanced Drive System:
- Permanent Magnet Synchronous Gearless Traction Machine — low noise, high efficiency, maintenance-free
- VVVF (Variable Voltage Variable Frequency) intelligent control for precise leveling and smooth start/stop
- 40% energy saving compared to traditional traction system
2. Safety First:
- Full-height infrared light curtain door protection
- ARD – Automatic Rescue Device in case of power failure
- Overload protection, overspeed governor, safety gear, and buffer system
- Emergency intercom and alarm system
- Complies with EN81, CE, ISO 9001:2015, and GB7588 standards
3. Cabin Design (As per FJT-9309):
- Hairline stainless steel + Mirror etching design with LED frame lighting
- Suspended false ceiling with energy-saving LED downlights and soft indirect lighting
- Premium PVC / marble flooring – anti-slip and wear-resistant
- Stainless steel handrail with rounded edges
- Ergonomic COP (Car Operation Panel) with dot-matrix display & Braille buttons
- Spacious and comfortable with excellent ventilation
4. Intelligent Control:
- FUJITHROUGH full computer modular control system
- Duplex, group control, and destination control system (DCS) optional
- Auto fault diagnosis with error code display
- Remote monitoring via IoT (optional)
5. Comfortable Experience:
- Precise leveling accuracy ±3mm
- Low vibration & noise <55dB inside cabin
- Smooth acceleration with S-curve comfort technology
Technical Specifications:
Capacity:
630kg, 800kg, 1000kg, 1350kg, 1600kg — ranging from 8 persons to 21 persons. Custom capacities available on request.
Rated Speed:
Available speeds: 1.0 m/s, 1.5 m/s, 1.75 m/s, 2.0 m/s, and up to 2.5 m/s. Optimized for smooth and efficient vertical transportation for low to high-rise buildings.
Machine Room Type:
Available in two configurations:
- Machine Room Less (MRL) — Saves building space, ideal for modern architecture.
- Small Machine Room — Compact design for flexible installation.
Control System:
Advanced VVVF Full Vector Control System — Ensures smooth starting and stopping, silent operation, precise leveling, and significant energy savings.
Door System:
Premium VVVF Door Operator with options for:
- Center Opening
- Side Opening
Fully customizable according to building design and shaft requirements.
Power Supply:
380V, 3-Phase, 50Hz — Standard industrial power supply, stable and reliable.
Travel Height:
Up to 150 meters as standard. For heights above 150 meters, custom engineering solutions are available according to project requirements.
