Features and Benefits

• EN54-7 Compliance
• Using microprocessor technology with memory capacity up to 10 events
• Analogue sending and digital addressing
• Provide real time algorithm to the control panel
• Smart linear drift compensation
• Onsite adjustable parameter
• 360 degree visual indicator
• Removable chamber against dust and small insect
• Ancillary remote indicator output
• Aesthetically pleasing design

Overview

The LF-X5100 Intelligent Addressable Optical Smoke Detector is the ideal device for most applications, due to its spiffing
linear response to a wide variety of different types of smoke patterns. The unit manufactured the sensitivity requirement
of EN 54 part 7, European Standard. The unit is aesthetically pleasing with unobtrusive design that will complement
modern building designs. The unit incorporates an intelligent processor that provides Algorithm map, inbuilt A/D converter, Drift compensation, and Self-Diagnosis and History log.
Secure and speedy communication through the on-board processor enables the detector to make its own decision,
resulting in greater automation. In the event of fire, the integral microprocessor analyses the signal according to factors
such as signal strength and rate of increase, then confirms these patterns with the pre-programmed fire scenarios and
smoke patterns, for a faster and safer response. Once it is confirmed, the LED indicates the sensor status and parallel
sending communication signal to the control panel. The LF-X5100 detector is compatible to the LF-X500 Analogue
Intelligent Fire Alarm Control Panel, produced by single manufacture LIFECO, to avoid addressable communication
compatibility problem.

Technical Specification

Listed LPCB Certification
Compliance EN54-7:2018
Input Voltage 24VDC [16V to 28V]
Current Consumption Standby 0.6mA, Alarm: 4mA
Protocol/Addressing LIFECO, Value range from 1 to 254
Sensitivity As per stipulated standard
Indicator Single LED / 360 degree Visual
Material / Colour ABS / White Glossy finishing
Dimension / Height Diameter 99.7 mm / 57 mm
Weight 145g (with Base), 90g (without Base)
Operating Temperature -10°C to +50°C
Humidity 0 to 95% Relative Humidity, Non condensing
